Specification Sheets
Collection-level data covering Mohs hardness, water absorption rate (<0.05%), flexural strength (40–60 MPa class), compressive strength context for substrate design, and finish options.
Technical Documentation Hub
Silestone Spec Sheets and CAD Files
Specification sheets, installation guides, CAD drawings, and engineering data organized for architects, fabricators, and project managers specifying Silestone quartz.
Documentation coverage at a glance
Live indicators of what the Silestone resource library currently publishes for professional specification teams.
Installation Guides
Edge profiles, overhang support, seam placement, and care routines for polished and textured finishes.
CAD Drawing Packs
DWG/DXF edge and cutout libraries for kitchen islands, vanity tops, and hospitality bar builds.
Engineering Notes
Thermal shock guidance, UV stability limits for outdoor collections, and jumbo slab handling notes.
Download technical documentation
Core files requested most often by specification writers and fabricators. Each entry notes format and typical use.
-
Request File
Silestone Master Specification Sheet
Performance summary for quartz countertops including abrasion resistance, VOC emissions pathway, and warranty period language.
-
Request File
Installation Guide — Kitchen Worktops
Sink cutout spacing, overhang support tables, and adhesive open-time notes for residential and multi-family kitchens.
-
Request File
CAD Edge Profile Library
Standard and specialty edge drawings for islands, waterfall ends, and bar tops in DWG format.
-
Request File
Jumbo Slab Size Reference
Available jumbo formats by collection with seam-reduction guidance for large hospitality runs.
-
Request File
HybriQ+ Recycled Content Declaration
Documented recycled content percentage and manufacturing notes for LEED and green-building submittal binders.
Documentation release timeline
How Silestone refreshes technical packs when collections, finishes, or compliance pathways change.
-
Q1
Collection data refresh
New color SKUs receive Mohs hardness, water absorption, and finish matrices before dealer launch kits ship.
-
Q2
CAD & install updates
Edge libraries and installation guides incorporate fabricator feedback on cutout density and thick-edge builds.
-
Q3
Compliance packet review
NSF, GREENGUARD Gold, and ISO documentation pathways are re-verified for active commercial collections.
-
Q4
Annual engineering digest
Thermal, UV stability, and jumbo handling notes consolidate into a year-end digest for specification libraries.
Technical limits to read before you specify
- Heat & thermal shock: Hot pots can leave thermal marks; use trivets. Published guidance covers typical kitchen exposure, not open-flame contact.
- Outdoor UV stability: Only collections labeled for exterior use should face prolonged UV; standard indoor quartz may fade or chalk outdoors.
- Overhang support: Flexural strength class does not remove the need for brackets or substrate support beyond published overhang tables.
- Metal marking: Soft metals can leave grey marks on polished finishes; these are usually removable and are not structural defects.
Need a custom specification pack?
Tell us the collection, square footage, and compliance pathway. We will assemble the sheets, CAD files, and engineering notes your submittal requires.
